Lockheed F-104 Starfighter
Aircraft of the United States Air Force
Development
Entwicklung
Variants
Versionen
Operational history
Einsatzgeschichte
Drawings Air National Guard
Zeichnungen Air National Guard
| F-104 Units of the Air National Guard | ||
| 151 FIS 134 FIG | Tennesee | 1960 - 1963 |
| 157 FIS 169 FIG | South Carolina | 1960 - 1963 |
| 197 FIS 161 FIG | Arizona | 1960 - 1962 |
| 198 TFS 156 TFG | Puerto Rico | 1967 - 1975 |
Drawings USAF
Zeichnungen USAF
| F-104 Units of the Air Force | |||
| 56 FIS | 30 AD | Wright-Patterson AF OH | 1958 - 1960 |
| 83 FIS | 78 FIG | Hamilton AFB CA. | 1957 - 1960 |
| 319 FIS | 30 AD | Homestead AFB FL | 1963 - 1969 |
| 331 FIS | 4752 ADW | Webb AFB TX | 1958 - 1967 |
| 337 FIS | Boston ADS | Westover AFB MA | 1958 - 1961 |
| 482 FIS | Montgomery ADS | Homestead AFB FL | 1965 - 1969 |
| 538 FIS | 4721 ADW | Larson AFB WA | 1958 - 1960 |
| 434 TFS | 479 TFW | George AFB CA | 1958 - 1965 |
| 435 TFS | 479 TFW | George AFB CA | 1958 - 1965 |
| 436 TFS | 479 TFW | George AFB CA | 1958 - 1965 |
| 476 TFS | 479 TFW | George AFB CA | 1958 - 1965 |
| 3410 CCTS | 58 TFTW* | Luka AFB AZ | 1969 - 1983 |
| 3412 CCTS | 58 TFTW* | Luka AFB AZ | 1969 - 1983 |
| 3418 CCTS | 58 TFTW* | Luka AFB AZ | 1969 - 1983 |
| 3443 CCTS | 58 TFTW* | Luka AFB AZ | 1969 - 1983 |
| * German Air Force also known as 4510 TFTG | |||
| Specifications |
F-104C |
|
|
Wingspan |
Spannweite |
6.36 m |
|
Length |
Länge |
16.66 m |
|
Height |
Höhe |
4.09 m |
|
Wing area |
Flügelfläche |
18.22 m² |
|
Engine |
Motor |
1 × General Electric J79-GE-11A afterburning turbojet 10,000 lbf Dry thrust 15,600 lbf afterburner |
|
Maximum speed |
Höchstgeschwindigkeit |
2,125 km/h |
|
Empty weight |
Leergewicht |
6,350 kg |
|
Loaded weight |
Startgewicht |
13,170 kg |
|
Climb Rate |
Steigrate |
244 m/s |
|
Service ceiling |
Gipfelhöhe |
15,000 m |
|
Range |
Reichweite |
670 km |
|
Armament |
Bewaffnung |
1 × 20 mm cannon |
