Grumman F-14 Tomcat
Aircraft of the U.S. Navy
Entwicklung
The .
Versionen
Initial two-seat all-weather interceptor fighter variant for the US Navy, 554 build.
Erste Produktionsversion für die US-Navy. 554 Maschinen gebaut.
Prototype of the F-14 with F401-P-400 engine. 2 planes build
Prototyp einer F-14 mit F401-P-400 Triebwerken. 2 Maschinen gebaut.
F-14B
F-14A+ later F-14B with GE F110-400 engine and AN/APG-71 Radar. 48 F-14A were upgraded and 38 new aircraft were manufactured.
F-14B
F-14A+ und später F-14B mit GE F110-400 Triebwerk und AN/APG-71-Radarsystem. 48 nachgerüstete Maschinen und 38 neue.
F-14D
final variant of the F-14 with GE F110-400 engines, 55 build
F-14D
Finale Version der F-14 mit GE F110-400 Triebwerk, 55 Stück
Einsatzgeschichte
The
Die
Zeichnungen
Fighter Squadrons
...
Test an Evolution Squadrons
| Specifications |
F-14A |
|
|
Wingspan |
Spannweite |
11,65 m - 19,55 m |
|
Length |
Länge |
19,10 m |
|
Height |
Höhe |
4,88 m |
|
Wing area |
Flügelfläche |
52,49 m² |
|
Engine |
Motor |
Zwei
Pratt & Whitney TF30P-412A-Mantel- |
|
Maximum speed |
Höchstgeschwindigkeit |
2.517 km/h |
|
Empty weight |
Leergewicht |
18.191 kg |
|
Loaded weight |
Startgewicht |
32.805 kg |
|
Climb Rate |
Steigrate |
229 m/s |
|
Service ceiling |
Gipfelhöhe |
17.070 m |
|
Range |
Reichweite |
1.167 km |
|
Armament |
Bewaffnung |
up to 6.577 kg |
| Serial, Grumman F-14 Tomcat | ||
| YF-14A | 157980 - 157991 | 12 |
| F-14A | 158612 - 158637 | 26 |
| F-14A | 158978 - 159025 | 48 |
| F-14A | 159421 - 159468 | 48 |
| F-14A | 159588 - 159637 | 50 |
| F-14A | 159825 - 159874 | 50 |
| F-14A | 160378 - 160414 | 37 |
| F-14A | 160652 - 160696 | 45 |
| F-14A | 160867 - 160930 | 64 |
| F-14A | 161133 - 161168 | 36 |
| F-14A | 161270 - 161299 | 30 |
| F-14A | 161416 - 161445 | 30 |
| F-14A | 161597 - 161626 | 30 |
| F-14A | 161850 - 181573 | 24 |
| F-14A | 162588 - 162611 | 24 |
| F-14A | 162688 - 162711 | 24 |
| F-14B | 162910 - 162927 | 18 |
| F-14B | 163215 - 163229 | 15 |
| F-14B | 163407 - 163411 | 5 |
| F-14D | 163412 - 163418 | 7 |
| F-14D | 163893 - 163904 | 12 |
| F-14D | 164340 - 164351 | 12 |
| F-14D | 164599 - 164604 | 6 |
|
Total |
653 |
|
